Size & Weight
DIMENSIONS (W X H X D)
18.13 in x 7.88 in x 18.59 in
WEIGHT
Approx. 28 lb (13 kg)
Display
DISPLAY SYSTEM
4K SXRD™ panel, projection system
DISPLAY RESOLUTION
720 x 576/50p, 720 x 480/60p, 1280 x 720/50p, 1280 x 720/60p, 1920 x 1080/50i, 1920 x 1080/60i, 1920 x 1080/24p, 1920 x 1080/50p, 1920 x 1080/60p, 1920 x 1080/120p, 3840 x 2160/24p, 3840 x 2160/25p, 3840 x 2160/30p, 3840 x 2160/50p, 3840 x 2160/60p, 4096 x 2160/24p, 4096 x 2160/25p, 4096 x 2160/30p, 4096 x 2160/50p, 4096 x 2160/60p
LIGHT SOURCE
Laser diode
PICTURE PROCESSOR
X1™ Ultimate for projector
General Features
CONTRAST RATIO
∞: 1 (Dynamic Contrast)
EFFECTIVE DISPLAY SIZE
0.61" x 3
EFFECTIVE PIXELS
24,883,200 (3840 x 2160 x 3) pixels
PROJECTION LENS SHIFT
Manual, Vertical +/- 71%, Horizontal +/- 25%
THROW RATIO
1.38:1 to 2.21:12
Hardware
PROJECTION LENS ZOOM / FOCUS
Manual (Approx. x1.60) / Manual
Interface
INPUT AND OUTPUT TERMINALS
HDMI (TWO INPUTS)3 - Digital RGB/Y Pb/Cb Pr/Cr, IR IN - Minijack, LAN - RJ45, 10Base-T/100BASE-TX, REMOTE - RS-232C, D-sub 9-pin (male), TRIGGER - Minijack, DC 12 V Max. 100 mA, USB - Type A, DC 5 V, Max. 500 mA
Operating Conditions
OPERATING TEMPERATURE / HUMIDITY
41 °F to 95 °F (5 °C to 35 °C) / 20% to 80% (no condensation)
STORAGE TEMPERATURE / HUMIDITY
14 °F to +140 °F (–10 °C to +60 °C ) / 20% to 80% (no condensation)
Power
ACOUSTIC NOISE
24 dB4
POWER REQUIREMENT
AC 100 V to 240 V, 50/60 Hz
POWER CONSUMPTION
295 W
Video Features
LIGHT OUTPUT
2,000 lm
COLOR LIGHT OUTPUT
2,000 lm
Eco and energy saving
POWER CONSUMPTION (STANDBY MODE)
0.3 W (When "Remote Start" is set to "Off")
POWER CONSUMPTION (NETWORKED STANDBY MODE) – TERMINALS
0.5 W (LAN) (when “Remote Start” is set to “On”) When a LAN terminal is not connected, it becomes a low power consumption mode (0.5 W)
STANDBY MODE ACTIVATED
After about 10 Minutes
Accessibility
SCREEN READER
Yes
